Applied to truck/machine brake system, transport air, oil, water, kerosene, oxygen and other media.
EMAIL:
info@orlete.comphone:
8613645184293Structure：NBR/Synthetic fiber braided layer/CR or EPDM/Synthetic fiber braided layer/EPDM
Medium：Compressed Air
Temperature：-40～120℃
Standard：GB 16897、FMVSS 106、SAE J1402
| TYPE | I.O mm |
D.O mm |
Max W.P MPa |
Min B.P MPa |
Minimum Bending Radius mm |
| Q1017 | 10 | 17 | 0.8 | 10 | 90 |
| Q1220 | 12 | 20 | 0.8 | 10 | 100 |
| Q1323 | 13 | 22.7 | 0.8 | 10 | 100 |
| Q1526 | 15 | 26 | 0.8 | 10 | 115 |
